Chip giant Intel (NASDAQ:INTC) has struggled mightily to bring its 10nm chip manufacturing technology into mass production at yield rates that it deems acceptable. That struggle has led to a multiyear delay in the mass production of its 10nm technology, which has led to numerous product delays and cancellations

In fact, Intel CEO Brian Krzanich indicated on the company's earnings conference call on April 26 that he's not sure yet whether this technology will go into mass production in the first or second half of 2019.

An Intel engineer inside of a chip manufacturing factory.

Image source: Intel.

Things simply aren't going well for the company's 10nm technology.

Also during that conference call, one analyst asked Krzanich if he expected the problems that Intel experienced during the 10nm generation to carry over to the follow-on generation, known as 7nm.

Krzanich was optimistic that those issues wouldn't; here's why.

Less aggressive goals

Krzanich said the company set "very aggressive goals" in terms of chip area reduction in going from its 14nm technology to its 10nm technology, aiming for a 2.7 times increase in logic density -- a reasonable boost from the company's historical target of a 2.4 times improvement in logic density.

Logic density affects how small and, ideally, cheap a chip is to manufacture. All else being equal, better density means a smaller and ultimately cheaper-to-build chip.

Krzanich conceded that Intel may have "bitten off more than it could chew" in trying to go for such a large leap in logic density. For the upcoming 7nm technology, the executive says the company is targeting a more typical 2.4-times improvement in logic density compared to its 10nm technology.

Use of EUV lithography

Krzanich also explained that the issues the company is grappling with regarding 10nm yields is that the technology uses traditional immersion lithography rather than extreme ultraviolet (EUV) lithography.

The technical details here aren't important, but what you need to know is that, assuming the EUV lithography equipment is available, it's generally much easier to pattern smaller chip features using EUV than it is with immersion lithography.

Krzanich says that because the company's 7nm technology will use EUV lithography rather than immersion lithography in many of the manufacturing steps, some of the critical issues that Intel ran into in the development of 10nm won't pop up again in the 7nm generation.

Foolish takeaway

Ultimately, I think Intel became so obsessed with "beating" the competition in the race to produce the densest chips during the 10nm generation that it designed a manufacturing technology that was more about winning an arbitrary contest than about delivering a technology on time to support all of the products it needs to build to support its businesses.

With the 7nm technology, at least based on what Krzanich has said, it looks like the company is going to back down from taking unnecessary risks just to win that contest and will instead focus on building a technology that'll actually arrive on time.

If Intel succeeds in getting its manufacturing technology development back on track with the introduction of 7nm -- and if it doesn't forget the painful lessons it learned during the 10nm generation -- then the company's future could be a lot brighter with fewer product delays and less manufacturing-related uncertainties.
